| Printing |
| Printing method | Direct thermal |
| Media width | 79.5±0.5mm / φ 80 mm |
| Print width | 72mm |
| Column capacity | 576 dots/line or 512 dots/line |
| Printing speed | 200mm/s | |
| Interface | USB+Lan /
(Optional: Bluetooth/Wifi) | |
| Line spacing | 3.75mm (Adjustable by commands) |
| Character size | ANK,Font A:1.5×3.0mm(12×24 dots) Font B:1.1×2.1mm(9×17 dots) Chinese,traditional Chinese:3.0×3.0mm(24×24 dots) |
| Barcode Character |
Extension character
sheet | PC347(Standard Europe)?Katakana?PC850(Multilingual)?PC860(Portuguese)?PC863(Canadian-French)?PC865(Nordic)?West Europe?Greek?Hebrew?East Europe?Iran?WPC1252?PC866(Cyrillic#2)?PC852(Latin2)?PC858?IranII?Latvian?Arabic?PT151(1251) |
| 1D Barcode | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 |
| 2D Barcode | QR CODE: Lan / USB+Lan | |
| Input buffer | 128 Kbytes: USB+Serial / USB / USB+Bluetooth/USB+WiFi
256 Kbytes: Lan / USB+Lan / USB+Serial+Lan |
| NV Flash | 256 Kbytes |
| Power |
| Power adaptor | Input: AC 100V/240V, 50~60Hz; Output:DC 24V/2.5A |
| Printer input | DC 24V/2.5A |
| Cash drawer | DC 24V/1A |
| Physical characteristics |
| Weight | 0.87 KG |
| Dimensions | 180*145*130mm (D×W×H) |
| Environmental Requirements |
| Work environment | Temperature (0~45?) humidity(10~80%) |
| Storage environment | Temperature(-10~60?) humidity(10~90%) |
| Reliability |
| Auto cutter | Partial |
| Cutter life | 1.5 million cuts |
| Printer head life | 150 KM |
| Software |
| Emulation | ESC / POS |
| Driver | Windows / Linux / Mac OS / Android |
